Description
Strong hydrotherapy for families and entertaining
The Maple M420 is a spacious open-seating spa designed for families, gatherings and homeowners who prefer multiple upright hydrotherapy positions over a single full-length lounge.
Its 50-jet system is powered by two 3.5 hp pumps: one dual-speed and one single-speed. This configuration provides stronger water movement and broader massage coverage than the plug-and-play models.
Premium details include LED waterline lighting, illuminated jets, illuminated valves and cup holders, two fountains, a volcano jet and a Gecko K1000 touchscreen control panel. Ozone sanitation is included, and the spa is pre-installed for the Gecko WaterLab system.
The combination of generous seating, powerful hydrotherapy and smart-water-care readiness makes the M420 a strong choice for larger households and entertaining.
Standard features
- Seven-person open seating
- 50 hydrotherapy jets
- One 3.5 hp dual-speed pump
- One 3.5 hp single-speed pump
- Volcano jet
- LED waterline lighting
- Illuminated jets
- Illuminated valves and cup holders
- Two fountains
- K1000 touchscreen keypad
- Ozone included
- Pre-installed WaterLab system
- Optional Wi-Fi
- Deluxe 5″/3″ cover
Optional upgrades
- Bluetooth audio
- WaterLab probe
- UV and ozone sanitation
- In.Clear advanced water care, where available
- Wi-Fi connectivity
| Specification | Value |
|---|---|
| Model | M420 |
| Collection | Maple Collection |
| Seating capacity | 7 people |
| Lounges | 0 |
| Seating layout | Open / non-lounge |
| Jets | 50 |
| Dimensions | 88″ × 75″ × 37″ |
| Metric dimensions | Approx. 224 × 191 × 94 cm |
| Water capacity | 1,255 litres / 332 US gallons |
| Pump 1 | One 3.5 hp dual-speed pump |
| Pump 2 | One 3.5 hp single-speed pump |
| Volcano jet | Included |
| Fountains | 2 |
| Control panel | Gecko K1000 touchscreen |
| Wi-Fi | Optional |
| Ozone | Included |
| WaterLab | Pre-installed; probe optional |
| Empty weight | 750 lb / approx. 340 kg |
| Filled weight | 3,524 lb / approx. 1,599 kg |
| Cover | Deluxe 5″/3″ cover |
| Electrical | 240V; final service requirement must be dealer-confirmed |
